Part No. | PD3.0 | Type-C Specs | OVP, UVP, OTP | Program Methods | ESD | Operation Current | Power Supply | Ambient Temperature | TID | Package | |
---|---|---|---|---|---|---|---|---|---|---|---|
HUSB236 | √ | V1.4 | - | Resisters or Capacitor or I2C | 6kV | 3.1mA@5V | 3.24V-21V | -40 °C to 85 °C | - | SOP-8L | |
HUSB237 | √(PD3.1) | V2.1 | - | Resisters or Capacitor | 2kV | 1.15mA@5V | 4.5 V-22 V | -40 °C to 85 °C | - | DFN2x2-6L,SOT23-5L | |
HUSB238A | √(PD3.1) | V2.1 | √ | Resisters/I2C | 4kV | 45 μA | 3 V-48 V | -40°C - 85°C | - | 3 mm x 3 mm QFN-16L | |
HUSB238 | √ | V1.4 | √ | Resisters/I2C | 6kV | 3mA | 3V-25V | -40°C - 85°C | 3666 | 3x3 DFN-10L |
